D-Link DSM-G600 [5/74] Introduction
![D-Link DSM-G600 [5/74] Introduction](/views2/1045701/page5/bg5.png)
5
DSM-G600 User’s Manual
D-Link Systems, Inc.
Introduction
Introduction
D-Link, an industry leader in networking, introduces the DSM-G600 Wireless G Network
Storage Enclosure. Connect your existing hard drives* to a home or office network
and create additional storage space with the DSM-G600 Wireless Network Storage
Enclosure. With the DSM-G600, you can conveniently share documents, files, and
digital media such as music, video, and photos with everyone on your home or office
network.
The DSM-G600 Wireless G Network Storage Enclosure can be used with an internal
3.5” PATA/IDE hard drive, giving you the flexibility of choosing the storage capacity
required for your network. And with two additional high-speed USB 2.0 ports, expand
your storage capabilities even further as your network needs grow by adding your own
external USB drives!
In addition, the DSM-G600 also functions as an Access Point. Create an 802.11g
wireless network when you attach the DSM-G600 to your wired router. This network
can be secured using WEP, WPA, or WPA-PSK encryption. With support for Windows
®
Connect Now, you can simplify wireless configuration.
By adding your own hard drives to the DSM-G600 Wireless G Network Storage
Enclosure, conveniently store, retrieve, and share digital content with everyone on
your home or office network. As a central storage location for data, the DSM-G600 is
an organized solution for the network.
Free up disk space on the computer and organize data on your network with the
DSM-G600 Wireless G Network Storage Enclosure!
* Hard Drives not included
