25
DSM-G600 User’s Manual
D-Link Systems, Inc.
Using the Setup Wizard (continued)
Click Next.
When selecting Client mode, you will need
to choose the connection mode:
Infrastructure - Connect to an access point
or wireless router.
Ad-Hoc - Connect to a wireless client
directly such as a laptop with a wireless
adapter.
Skip to page 26 for Access Point mode.
Click Site Survey to select a network from
a list of available wireless networks or you
may enter the wireless settings manually.
The SSID must be the same for all devices
in the network.
Click the radio button next to the wireless
network you want to connect to.
Click Connect.
If you have already configured the wireless settings using Windows
®
Connect Now (WCN),
click Next on the following screen without any configuration changes. Refer to page 13 for WCN
setup instructions.
Note: The DSM-G600 cannot bridge two existing wireless networks via wireless. Plugging the
unit into a router, switch, or hub using an Ethernet cable will allow you to create a wireless
network or s
egment.
