17
DSM-G600 User’s Manual
D-Link Systems, Inc.
Select an available wireless
network by clicking on the radio
button under Join.
Your wireless connection setup is now complete!
Connecting to a Wireless Network
Click Connect
Connecting to a Wireless Network (continued)
Click Apply
If the wireless network you’ve selected has any
wireless security enabled, you will be prompted
to enter the WEP or WPA-PSK information.
Refer to page 29 for more information regarding
encryption.
Next, click Wireless on the left side and select Client
mode.
Click Enable
Click Site Survey
