DGS-1210 Metro Ethernet Managed Switch CLI Reference Guide

198

Description

The show scheduling command displays the current configuration

for the maximum number of packets (max_packet) value assigned to

the four priority classes of service on the Switch. The Switch empties

the four hardware queues in order, from the highest priority (class 3)

to the lowest priority (class 0).

Parameters None.

Restrictions None.

Example usage:

To display the current scheduling configuration:

DGS-1210-28MP/ME:5# show scheduling

Command: show scheduling

QOS Output Scheduling

Class ID Weight

-------- ----------

Class-0 strict

Class-1 strict

Class-2 strict

Class-3 strict

Class-4 strict

Class-5 strict

Class-6 strict

Class-7 strict

DGS-1210-28MP/ME:5#

config bandwidth_control

Purpose To configure bandwidth control on the Switch.

Syntax

config bandwidth control [<portlist> | all] {rx_rate [no_limit |

<value 63-1000000>] | tx_rate [no_limit | <value 63-1000000>]}

Description

The config bandwidth_control

command defines bandwidth

control.

Parameters

portlist - A port or range of ports to be configured.

all - Specifies that the config bandwidth_control command applies

to all ports on the Switch.

rx_rate - Enables ingress rate limiting

• no_limit – Indicates no limit is defined.

• <value 63–1000000>] – Indicates a range between 63-

1000000 kbps.

tx_rate – Enables egress rate limiting.

• no_limit – Indicates no limit is defined.

• <value 63–1000000>] – Indicates a range between 63-

1000000 kbps.

Restrictions Only administrator-level users can issue this command.

Example usage:
