DGS-1210/ME Metro Ethernet Switch CLI Reference Guide

395

REMOTE SWITCHED PORT ANALYZER COMMANDS

The Remote Switched Port Analyzer (RSPAN) commands in the Command Line Interface (CLI) are listed (along

with the appropriate parameters) in the following table.

Command

Parameter

enable rspan

disable rspan

create rspan vlan [<vlan_name 32> | vlanid <vlanid_list> ]

config rspan vlan

[<vlan_name 32> | vlanid <vlanid_list>] [redirect [add | delete] ports <portlist> |

source [add | delete] ports <portlist> [rx|tx|both] target <port 1-28> ]

delete rspan vlan

show rspan

Each command is listed in detail, as follows:

enable rspan

Purpose

Used to enable the RSPAN function. The purpose of the RSPAN

function is to mirror packets to a remote switch. A packet travels

from the Switch where the monitored packet is received, passing

through the intermediate switch, and then to the Switch where the

sniffer is attached. The first switch is also named the source switch.

To make the RSPAN function work, the RSPAN VLAN source

setting must be configured on the source switch. For the

intermediate and the last switch, the RSPAN VLAN redirect setting

must be configured.

Syntax

enable rspan

Description

The enable rspan command is used to enable the RSPAN function.

Parameters None.

Restrictions Only Administrator, operator and power user-level users can issue

this command.

Example usage:

To enable RSPAN state:

DGS-1210-28MP/ME:5# enable rspan

Command: enable rspan

Success.

DGS-1210-28MP/ME:5#
