DGS-1210/ME Metro Ethernet Switch CLI Reference Guide

363

config limited_multicast_addr

Purpose To configure the multicast address filtering function a port.

Syntax

config limited_multicast_addr ports <portlist> [ipv4 | ipv6] {[add

| delete] [profile_id <integer 1-24> | profile_name <string 20>] |

access [permit | deny]}

Description

The config limited_multicast_addr command is used to configure

the multicast address filtering function on a port. When there are no

profiles specified with a port, the limited function is not effective.

Parameters

ports <portlist> –

A port or range of port on which the limited

multicast address range to be configured has been assigned.

[ipv4 | ipv6] – Specify the IPv4 or IPv6 of multicast filter profile to be

configured.

[add | delete] – Add or delete a multicast address profile to a port.

profile_id <integer 1-24> – A profile ID to be added or deleted from a

port.

profile_name <string 20> – A profile name to be added or deleted

from a port.

[permit | deny] –

Specifies that the packet that matches the

addresses defined in the profiles will be permitted or denied

. The

default mode is permit.

Restrictions Only Administrator or operator-level users can issue this command.

Example usage:

To configure ports 1 and 3 to set the IPv6 multicast address profile id 1:

DGS-1210-28MP/ME:5# config limited_multicast_addr ports 1,3 ipv6 add profile_id 1

Command: config limited_multicast_addr ports 1,3 ipv6 add profile_id 1

Success.

DGS-1210-28MP/ME:5#

show limited_multicast_addr

Purpose Used to show the per-port Limited IP multicast address range.

Syntax

show limited_multicast_addr ports <portlist> {[ipv4 | ipv6]}

Description

The show limited_multicast_addr command is to di

splay the

multicast address range by port or by VLAN.

Parameters

<portlist> – Used to show the per-port Limited IP multicast address

range.

[ipv4 | ipv6] – Specify the IPv4 or IPv6 of limited multicast address to

be displayed.

Restrictions None.

Example usage:

To show the IPv4 limited multicast address on ports 1 and 3:

DGS-1210-28MP/ME:5# show limited_multicast_addr ports 1,3 ipv4

Command: show limited_multicast_addr ports 1,3 ipv4

Port Access Profile ID List

---- ----------- --------------------------------------------------------------
