DGS-1210 Metro Ethernet Managed Switch CLI Reference Guide

242

Restrictions Only Administrator, operator and power user-level users can issue

this command.

Example usage:

To disable the revertive of R-APS VLAN 4094:

DGS-1210-28MP/ME:5# config erps raps_vlan 4094 revertive disable

Command: config erps raps_vlan 4094 revertive disable

Success.

DGS-1210-28MP/ME:5#

delete erps raps_vlan

Purpose Used to delete an R-APS VLAN on the switch. When an R-APS

VLAN is deleted, all parameters related to thie R-APS VLAN will also

be deleted. This command can only be issued when the ring is not

active.

Syntax

delete erps raps_vlan <vlanid 1-4094>

Description

The delete erps raps_vlan is used to delete the R-APS VLAN on

the switch.

Parameters

<vlanid 1-4094> - Specify the VLAN ID .

Restrictions Only Administrator, operator and power user-level users can issue

this command.

Example usage:

To delete an ERPS RAPS VLAN:

DGS-1210-28MP/ME:5#DGS-1210-28MP/ME:5# delete erps raps_vlan 4094

Command: delete erps raps_vlan 4094

Success.

DGS-1210-28MP/ME:5#DGS-1210-28MP/ME:5#

show erps

Purpose Used to display ERPS configuration and operation information.

The port state of the ring port may be as "Forwarding", "Blocking",

"Signal Fail". "Forwarding" indicates that traffic is able to be

forwarded. "Blocking" indicates that traffic is blocked by ERPS and a

signal failure is not detected on the port. "Signal Fail" indicates that a

signal failure is detected on the port and traffic is blocked by ERPS.

The RPL owner administrative state could be configured to

"Enabled" or "Disabled". But the RPL owner operational state may

different from the RPL owner administrative state, for example,

the RPL owner conflict occurs. "Active" is used to indicate that the
