Epson GT-9500 [24/54] Scanning start

22 7/8/96-B

Scanning start

(1) Code: ESC G

ASCII: ESC G

decimal: 27,71

hexadecimal: 1B,47

(2) Function: Starts a scanning operation (image reading), and the

reading data is sent to the host computer.

(3) Handshaking

1) ESC G code

2) Data-Block

3) ACK( 06H )

4) The last reading Data-Block from the scanner

NOTE 1:After accepting the last reading Data-Block, the host should not send

ACK to the scanner.

NOTE 2:The area end flag is set in the last reading Data-Block.
