Epson GT-9500 [25/54] Abort scanning

7/8/96-B 23

Abort scanning

(1) Code: CAN

ASCII: CAN

decimal: 24

hexadecimal: 18

(2) Function: Terminates a scanning operation, and the scanner returns to the command waiting

mode. An ACK code is returned from the scanner.

(3) Handshaking

1) Reading Data-Block from the scanner

2) ACK ( 06H )

3) CAN ( 15H )

NOTE1: The CAN code is available only when the scanner is waiting for an ACK

code during a scanning operation.

NOTE2: As the ACK code is returned from the scanner after receiving the CAN

code, the HOST should receive.
