52 7/8/96-B
216mm
1.6 ± 0.5mm
1 ± 0.5mm
297mm
Origin point
The area of glass
The readable area
7. Manuscript table
[Dimension] 216mm(Horizontal) * 297mm(Vertical)
Origin point
