Epson GT-9500 [47/54] Set auto area segmentation

7/8/96-B 45

Set auto area segmentation

(1) Code: ESC s

ASCII: ESC s i

decimal: 27,115 i

hexadecimal: 1B,73 i

(2) Function Control auto area segmentation(AAS).

i=00H :Disable AAS

i=01H :Enable AAS(Text area =Fixed threshold, Photo area =[ESC B])

(3) Handshaking

1) ESC s code

2) ACK( 06H )

3) i (1 byte)
