Epson GT-9500 [27/54] Status flag request

7/8/96-B 25

Status flag request

(1) Code: ESC F

ASCII: ESC F

decimal: 27,70

hexadecimal: 1B,46

(2) Function: Requests the scanner to send the Data-Block that

identifies the status of the scanner.

(3) Handshaking

1) ESC F code

2) Data-Block

(4) Contents of Data-Block

< Data > <Description >

STX( 02H ) :Header

?? :Status byte (1 byte)

00 :Number of data (2 bytes)
