Set color correction

(1) code: ESC M

ASCII: ESC M i

decimal: 27,77 i

hexadecimal: 1B,4D i

(2) Function: Sets the color correction table for the selected output

device.

i = 00H : No Correction

i = 01H : User defined

i = 10H : Impact-dot printers

i = 20H : Thermal printers

i = 40H : Ink-jet printers

i = 80H : CRT monitors

default value: i = 80H

(3) Handshaking

1) ESC M code

2) ACK( 06H )

3) The parameter for color correction i.

Note: This command is available in line/byte sequence mode.
