7/8/96-B 43
Resident Dither pattern
Dither
pattern
Threshold
value
Dither
pattern
Threshold
value
How to decide a bi-level image data.
Dij < Tij then Bij = 0 (Dij: Input image data Bij:bi-level image data)
Dij ≥ Tij then Bij = 1 (Tij: Threshold value ij: Position of pixel)
[A]4*4Bayer [B]4*4Spiral [C]4*4Net screen
1571310 2981 1296
3 11 1 6 10 15 14 7 3 15 14 8
12 4 14 9 11 12 13 6 10 12 13 5
0825 3450 71140
êêê
248 120 216 88 40 152 136 24 24 40 152 104
56 184 24 152 168 248 232 120 56 248 232 136
200 72 232 104 184 200 216 104 168 200 216 88
8 136 40 168 56 72 88 8 120 184 72 8
[D]8*8Net screen
2923608122028
22 5 1 17 16 11 13 21
4 2 18 26 25 15 10 9
3192731302414 7
81220282923 6 0
16 11 13 21 22 5 1 17
2515109421826
30 24 14 7 3 19 27 31
ê
236 188 52 4 68 100 164 228
180 44 12 140 132 92 108 172
36 20 148 212 204 124 84 76
28 156 220 252 244 196 116 60
68 100 164 228 236 188 52 4
132 92 108 172 180 44 12 140
204 124 84 76 36 20 148 212
244 196 116 60 28 156 220 252
