Epson GT-9500 [42/54] Down load the gamma table

40 7/8/96-B

Down load the gamma table

(1) Code: ESC z

ASCII: ESC z i d(256)

decimal: 27,122, i, d1,d2 ... ,d256

hexadecimal: 1B,7A, i, d1,d2, ... ,d256

(2) Function: Down load gamma data(256 bytes) in order to set the gamma table

in the scanner. The gamma table has a color attribution and it

should be specified by the parameter ‘i’.

i = ‘m’ or ‘M’ : Monochrome

i = ‘r’ or ‘R’ : Red

i = ‘g’ or ‘G’ : Green

i = ‘b’ or ‘B’ : Blue

Default value : i=’m’ or ‘M’

(3) Handshaking

1) ESC z code

2) ACK( 06H )

3) Color attribution (i) and Gamma table data (256 bytes)
