BIOS Setup - 28 -

(Note) The number of LAN ports listed will depend on the motherboard / system model.

Parameter

Description

AGESA PI Version

PI Version Displays AGESA PI version information.

Onboard LAN Information

LAN1 MAC Address

(Note)

Displays LAN MAC address information.

LAN2 MAC Address

(Note)

Displays LAN MAC address information.

System Date

Sets the date following the weekday-month-day-year format.

System Time

Sets the system time following the hour-minute-second format.
