BM-525 Bandwidth Management Gateway User’s Manual

- 189 -

7.10 WAN

STEP 1﹒Enter WAN in Statistics function, it will display all the statistics of

Downstream/Upstream packets and Downstream/Upstream record that pass WAN

Interface.

 Time: To detect the statistics by minutes, hours, days, months, or years.

WAN Statistics is the additional function of WAN Interface. When enable WAN Interface, it will

enable WAN Statistics too.
