6
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
@6 MEMORY CLEAR/5/14 MHz BAND KEY
M-CL
➥ Push and hold for 1 sec. to clear the
displayed memory channel contents in
memory mode. (p. 64)
• “ ” appears above the memory chan-
nel number.
➥ Push and hold for 1 sec., to select a
default condition or value when in set
mode/quick set mode. (p. 70)
5
14
➥ Push
F-INP ENT
BAND
, then push this key to in-
put the number ‘5.’ (p. 25)
➥
Push and hold
F-INP ENT
BAND
for 1 sec., then
push this key to select the 14 MHz band.
(p. 24)
@7 A
GC/6/18 MHz BAND KEY
AGC
➥ Push to toggle the time constant for
the AGC circuit fast and slow. (p. 45)
• “F.AGC” appears on the display when
fast AGC is selected; no indication ap-
pears when slow AGC is selected
➥ Push and hold for 1 sec. to turn the
AGC function OFF.
• “AGC-OFF” appears on the display.
6
18
➥ Push
F-INP ENT
BAND
, then push this key to
input the number ‘6.’ (p. 25)
➥
Push and hold
F-INP ENT
BAND
for 1 sec.,
then push this key to select the
18 MHz band. (p. 24)
@8 SPEECH COMPRESSOR/7/21 MHz BAND KEY
COMP
➥ Push to turn the speech compressor
function ON or OFF. (p. 57)
• “ ” appears on the display when the
speech compressor function is turned ON.
➥ Push and hold for 1 sec. to enter the
speech compression level set mode;
push again to return to normal operation.
7
21
➥ Push
F-INP ENT
BAND
, then push this key to in-
put the number ‘7.’ (p. 25)
➥
Push and hold
F-INP ENT
BAND
for 1 sec., then
push this key to select the 21 MHz band.
(p. 24)
@9 SCAN/8/24 MHz BAND KEY
SCAN
Push to start/stop the programmed/
memory scan in VFO/memory mode.
(p. 66)
• “ ” appears on the display during scan.
8
24
➥ Push
F-INP ENT
BAND
, then push this key to
input the number ‘8.’ (p. 25)
➥
Push and hold
F-INP ENT
BAND
for 1 sec.,
then push this key to select the
24 MHz band. (p. 24)
#0 VOX/9/28 MHz BAND KEY
VOX
➥ Push to turn the VOX function ON or
OFF. (p. 53)
➥ Push and hold for 1 sec. to enter VOX
set mode; push again to return to nor-
mal operation.
9
28
➥ Push
F-INP ENT
BAND
, then push this key to
input the number ‘9.’ (p. 25)
➥
Push and hold
F-INP ENT
BAND
for 1 sec.,
then push this key to select the
28 MHz band. (p. 24)
4 What is the VOX function?
The VOX function (Voice-Operated Transmission)
activates the transmitter when you speak into the
microphone and automatically returns to receive
when you stop speaking.
#1 MANU
AL NOTCH FILTER/0/50 MHz BAND KEY
MNF
➥ Push to turn the manual notch filter func-
tion ON or OFF. (p. 51)
• “ ” appears on the display when the
manual notch filter function is turned ON.
➥ Push and hold for 1 sec. to enter the
manual notch set mode; push again to
return to normal operation. (p. 52)
0
50
➥ Push
F-INP ENT
BAND
, then push this key to in-
put the number ‘0.’ (p. 25)
➥
Push and hold
F-INP ENT
BAND
for 1 sec., then
push this key to select the 50 MHz band.
(p. 24)
#2 RIT/•/GENERAL B
AND KEY
RIT
➥
Push to turn the RIT (Receiver Incremen-
tal Tuning) function ON or OFF. (p. 44)
• “ ” appears on the display when the RIT
function is turned ON.
• RIT frequency can be adjusted with [M-CH]
control when RIT mode is selected.
➥ Push and hold for 1 sec. to add the RIT
shift frequency to the operating fre-
quency. (p. 44)
•
Available only when the XFC (transmit fre-
quency check function) is turned OFF. (p. 76)
•
GENE
➥ Push
F-INP ENT
BAND
, then push this key to in-
put the number ‘• (decimal point).’ (p. 25)
➥
Push and hold
F-INP ENT
BAND
for 1 sec., then
push this key to select the general cover-
age band. (p. 24)
#3 FREQ
UENCY INPUT/ENTER/BAND KEY
F-INP ENT
BAND
➥ Push to enter the direct frequency in-
put condition. (p. 25)
➥ Push and hold for 1 sec., then push a
key on the keypad to select the oper-
ating band. (p. 24)
•
•
GENE
selects the general coverage band.
