Si21-205A Outdoor Unit (50/60 class)
Removal Procedure 291
2. Remove the fan motor.
1
Disconnect the
connector for fan motor
(S70).
2
The illustration shows
arrangement of the fan
motor lead wire.
Step
Procedure Points
