Si21-205A Method of Field Set (Reset after Maintenance Inspection/Repair)
Field Setting 63
After Setting Stick the Unit No. label at decoration panel air discharge outlet as well as on the back of the
wireless remote controller.
PRECAUTIONS
Set the Unit No. of the receiver and the wireless remote controller to be equal. If the settings
differ, the signal from the remote controller cannot be transmitted.
Wireless remote controller
Unit No. label
Decoration
panel
1
