Sony HCD-DZ720 Service Manual онлайн
SERVICE MANUAL
Sony Corporation
Home Audio Division
Published by Sony Techno Create Corporation
E Model
Australian Model
SUPER AUDIO CD/DVD RECEIVER
9-887-191-02
2006I16-1
© 2006.09
Ver. 1.1 2006.09
HCD-DZ720
HCD-DZ720 is the amplifier, DVD/CD and tuner
section in DAV-DZ720.
SPECIFICATIONS
Model Name Using Similar Mechanism HCD-DZ110
Mechanism Type CDM85-DVBU102
Optical Pick-up Name
KHM-310CAA
This system incorporates with Dolby*
1
Digital and Dolby Pro Logic (II)
adaptive matrix surround decoder and the DTS*
2
Digital Surround
System.
*1 Manufactured under license from Dolby Laboratories.
“Dolby,” “Pro Logic,” and the double-D symbol are trademarks of
Dolby Laboratories.
*2 Manufactured under license from Digital Theater Systems, Inc.
“DTS” and “DTS Digital Surround” are trademarks of Digital
Theater Systems, Inc.
Amplifier section
Stereo mode (rated) 108 W + 108 W (3 ohms at
1 kHz, 1 % THD)
Surround mode (reference)
RMS output power, 10 %
THD
Front: 143 W + 143 W
(with SS-TS53)
Center*: 143 W
(with SS-CT51)
Surround*: 143 W + 143
W
(with SS-TS53)
Subwoofer*: 285 W
(with SS-WS52B)
*Depending on the sound field settings and the source,
there may be no sound output.
Inputs (Analog)
TV/VCR (AUDIO IN) Sensitivity: 450/250 mV
AUDIO IN Sensitivity: 250/125 mV
Outputs (Analog)
Phones Accepts low-and high-
impedance headphones.
Super Audio CD/DVD system
Laser Semiconductor laser
(Super Audio CD/DVD:
λ = 650 nm)
(CD: λ = 790 nm)
Emission duration:
continuous
Signal format system NTSC/PAL
Tuner section
System PLL quartz-locked digital
synthesizer system
FM tuner section
Tuning range 87.5-108.0 MHz (50 kHz
step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Middle Eastern models: 531-1,602 kHz (with the
interval set at 9 kHz)
Asian models: 531-1,602 kHz (with the
interval set at 9 kHz)
530-1,710 kHz (with the
interval set at 10 kHz)
Antenna (aerial) AM loop antenna (aerial)
Intermediate frequency 450 kHz
Video section
Outputs VIDEO: 1 Vp-p 75 ohms
S VIDEO:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
COMPONENT:
Y: 1 Vp-p 75 ohms
P
B
/C
B
, P
R
/C
R
: 0.7 Vp-p
75 ohms
HDMI OUT: Type A (19
pin)
Inputs TV/VCR: 1 Vp-p 75 ohms
General
Power requirements 220 - 240 V AC, 50/60 Hz
Power consumption On: 160 W
Standby: 0.3 W (at the
Power Saving Mode)
Dimensions (approx.) 430 × 55 × 390 mm
(w/h/d) incl. projecting
parts
Mass (approx.) 4.0 kg
Design and specifications are subject to change
without notice.
