88
HCD-DZ720
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MS-203
R3151 1-216-809-11 METAL CHIP 100 5% 1/10W
R3152 1-216-809-11 METAL CHIP 100 5% 1/10W
R3153 1-216-797-11 METAL CHIP 10 5% 1/10W
R3154 1-216-864-11 SHORT CHIP 0
R3157 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3165 1-216-797-11 METAL CHIP 10 5% 1/10W
R3166 1-216-797-11 METAL CHIP 10 5% 1/10W
R3169 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3170 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3171 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3172 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3173 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3174 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3175 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3176 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3177 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3201 1-216-809-11 METAL CHIP 100 5% 1/10W
R3202 1-216-809-11 METAL CHIP 100 5% 1/10W
R3203 1-216-797-11 METAL CHIP 10 5% 1/10W
R3204 1-216-864-11 SHORT CHIP 0
R3207 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3215 1-216-797-11 METAL CHIP 10 5% 1/10W
R3216 1-216-797-11 METAL CHIP 10 5% 1/10W
R3219 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3220 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3221 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3222 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3223 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3225 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3226 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3227 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3251 1-216-809-11 METAL CHIP 100 5% 1/10W
R3252 1-216-809-11 METAL CHIP 100 5% 1/10W
R3253 1-216-797-11 METAL CHIP 10 5% 1/10W
R3254 1-216-864-11 SHORT CHIP 0
R3257 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3265 1-216-797-11 METAL CHIP 10 5% 1/10W
R3266 1-216-797-11 METAL CHIP 10 5% 1/10W
R3269 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3270 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3271 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3272 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3273 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3274 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3275 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3276 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3277 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3301 1-216-809-11 METAL CHIP 100 5% 1/10W
R3302 1-216-809-11 METAL CHIP 100 5% 1/10W
R3303 1-216-797-11 METAL CHIP 10 5% 1/10W
R3304 1-216-864-11 SHORT CHIP 0
R3307 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3315 1-216-797-11 METAL CHIP 10 5% 1/10W
R3316 1-216-797-11 METAL CHIP 10 5% 1/10W
R3319 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3320 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3321 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3322 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3323 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3324 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3326 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3327 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3401 1-216-809-11 METAL CHIP 100 5% 1/10W
R3402 1-216-809-11 METAL CHIP 100 5% 1/10W
R3403 1-216-797-11 METAL CHIP 10 5% 1/10W
R3404 1-216-864-11 SHORT CHIP 0
R3407 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3415 1-216-797-11 METAL CHIP 10 5% 1/10W
R3416 1-216-797-11 METAL CHIP 10 5% 1/10W
R3419 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3420 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3421 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3423 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3424 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3425 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3426 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3427 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3501 1-216-809-11 METAL CHIP 100 5% 1/10W
R3502 1-216-809-11 METAL CHIP 100 5% 1/10W
R3503 1-216-797-11 METAL CHIP 10 5% 1/10W
R3504 1-216-864-11 SHORT CHIP 0
R3507 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3515 1-216-797-11 METAL CHIP 10 5% 1/10W
R3516 1-216-797-11 METAL CHIP 10 5% 1/10W
R3519 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3520 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3551 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3554 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3555 1-216-864-11 SHORT CHIP 0
R4002 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X501 1-795-058-21 VIBRATOR, CERAMIC 5MHz
X3051 1-795-660-21 QUARTZ CRYSTAL UNIT 49.152MHz
*************************************************************
MS-203 BOARD
*************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION
*************************************************************
MAIN
