89
HCD-DZ720
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1144-950-A POWER BOARD, COMPLETE (KR)
A-1178-430-A POWER BOARD, COMPLETE (E3, SP, AUS)
***********************
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10 275V
0 C903 1-112-333-11 ELECT (BLOCK) 330uF 20% 450V
0 C905 1-112-335-91 FILM 0.0033uF 5% 400V
0 C906 1-117-815-11 FILM 1000PF 3% 1.5KV
0 C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
0 C908 1-107-909-11 ELECT 47uF 20% 35V
0 C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
0 C910 1-126-965-91 ELECT 22uF 20% 50V
0 C911 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C913 1-117-693-11 CERAMIC 100PF 10% 250V
0 C918 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C920 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C922 1-128-560-11 ELECT 22uF 20% 100V
0 C923 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C924 1-126-961-11 ELECT 2.2uF 20% 50V
0 C925 1-107-974-81 CERAMIC 47PF 5% 2KV
0 C928 1-113-900-11 CERAMIC 470PF 10% 250V
0 C929 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0 C930 1-117-693-11 CERAMIC 100PF 10% 250V
C932 1-100-924-21 ELECT 2200uF 20% 35V
C933 1-100-924-21 ELECT 2200uF 20% 35V
C934 1-112-831-11 ELECT 2200uF 20% 35V
C935 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C936 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C937 1-100-756-91 CERAMIC CHIP 0.047uF 50V
0 C938 1-117-698-51 CERAMIC 680PF 10% 250V
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-128-947-31 ELECT 3300uF 20% 10V
C941 1-128-954-11 ELECT 1000uF 20% 25V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-933-11 ELECT 100uF 20% 16V
C944 1-128-951-21 ELECT 2200uF 20% 16V
C945 1-126-935-11 ELECT 470uF 20% 16V
C946 1-128-950-21 ELECT 1000uF 20% 16V
C947 1-104-658-91 ELECT 100uF 20% 10V
C948 1-126-925-91 ELECT 470uF 20% 10V
C949 1-165-722-11 ELECT 100uF 20% 10V
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C952 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C953 1-117-214-11 CERAMIC 0.001uF 10% 2KV
C954 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C955 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C958 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C960 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0 C963 1-117-699-11 CERAMIC 0.001uF 99% 250V
0 C964 1-117-699-11 CERAMIC 0.001uF 99% 250V
C965 1-117-699-11 CERAMIC 0.001uF 99% 250V
C967 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C968 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C969 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C970 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C971 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
0D901 8-719-082-57 DIODE D5SBA60F01
0D905 8-719-063-74 DIODE D1NL20U-TR2
0D906 6-501-193-01 DIODE 1SS355WTE-17
0D907 6-501-193-01 DIODE 1SS355WTE-17
0D908 6-501-193-01 DIODE 1SS355WTE-17
0D909 6-501-193-01 DIODE 1SS355WTE-17
0D910 6-501-193-01 DIODE 1SS355WTE-17
0D913 6-500-241-01 DIODE SARS03
0D914 6-501-193-01 DIODE 1SS355WTE-17
0D915 8-719-977-28 DIODE UDZSTE-1710B
0D921 6-501-424-01 DIODE STO2D-140
0D922 8-719-063-74 DIODE D1NL20U-TR2
0D923 8-719-977-28 DIODE UDZSTE-1710B
0D924 8-719-083-69 DIODE UDZSTE-1724B
0D925 8-719-069-54 DIODE UDZSTE-175.1B
0D926 8-719-977-28 DIODE UDZSTE-1710B
D931 6-501-413-01 DIODE FCU20UC20
D932 8-719-069-54 DIODE UDZSTE-175.1B
D941 6-500-288-11 DIODE EK19LF-F7
D942 8-719-080-53 DIODE RK36LF-B3
D943 8-719-080-53 DIODE RK36LF-B3
D944 6-500-288-11 DIODE EK19LF-F7
D945 8-719-083-67 DIODE UDZSTE-1720B
< GROUND TERMINAL BOARD >
EB902 1-537-770-21 TERMINAL BOARD, GROUND
EB903 1-537-770-21 TERMINAL BOARD, GROUND
EB904 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE HOLDE >
0FH901 1-533-313-11 FUSE HOLDER 0A 0V
0FH902 1-533-313-11 FUSE HOLDER 0A 0V
< FUSIBLE >
0FR901 1-220-886-11 FUSIBLE 0.1 10% 1W
< IC >
0IC901 6-707-742-01 IC STR-F6168-LF1352
0IC921 6-707-740-01 IC STR-V153
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-707-746-01 IC SI-3120KM-TL
IC942 6-707-745-10 IC SI-3050KM-TL
IC943 6-707-744-01 IC SI-3033KM-TL
IC951 6-707-743-01 IC TA76L431S (TPE6, Q)
< COIL >
L931 1-457-226-11 INDUCTOR 10uH
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
