Sony HCD-DZ720 [15/92] 3 fl board
![Sony HCD-DZ720 [15/92] 3 fl board](/views2/1793005/page15/bgf.png)
15
HCD-DZ720
3-4. JACK BOARD, SW BOARD
3-3. FL BOARD
4
shield plate (fs)
0
FL board
9
wire (flat type)
23core (CN801)
7
wire (flat type)
13core (CN805)
3
five
screws (+BVTP 2.6
×
8)
1
three rivets
2
retainer K
5
screw (+BVTP 2.6
×
8)
6
connector (CN803)
8
connector (CN811)
1
knob (vol)
2
nut
5
JACK board
6
button base
assy (play)
4
wire (flat type)
13core (CNP802)
qa
connector (CNP801)
3
six
screws (+BVTP 2.6)
qs
two
screws
(+BVTP 2.6)
qf
button base
assy (power)
qd
SW board
q;
button base
(play)
8
cap (PLAY)
9
two
caps (AMS)
7
four
caps (FUNC)
qh
cap (power)
qg
button base (power)
