77
HCD-DZ720
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FB112 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB115 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB123 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB601 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB602 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB603 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB604 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB605 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB606 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL601 1-234-177-21 FILTER, CHIP EMI
FL602 1-233-893-21 FILTER, CHIP EMI
FL603 1-234-177-21 FILTER, CHIP EMI
FL701 1-234-177-21 FILTER, CHIP EMI
FL703 1-234-177-21 FILTER, CHIP EMI
FL704 1-234-177-21 FILTER, CHIP EMI
FL705 1-234-177-21 FILTER, CHIP EMI
FL4501 1-234-177-21 FILTER, CHIP EMI
< IC >
IC101 6-706-727-01 IC CXD9804R
IC102 6-806-676-01 IC S29AL032D70TF-OHI1-0611CE (E3, AUS)
IC102 6-806-677-01 IC S29AL032D70TF-OHI1-0611GA (SP, KR)
✩ IC103 not supplied IC BR24L64F-WE2
IC104 6-707-897-01 IC EDS6416AHTA-75-E
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC111 6-704-100-01 IC TC7PAU04FU (TE85R)
IC150 6-703-046-01 IC SN74LVC1G08DCKR
IC201 6-704-524-01 IC FAN8036L
IC701 6-708-682-01 IC CXD9873Q
IC702 6-702-300-01 IC TK11118CSCL-G
IC703 6-702-302-01 IC TK11133CSCL-G
IC705 6-703-046-01 IC SN74LVC1G08DCKR
✩ IC706 not supplied IC BR24L16F-WE2
IC707 6-705-337-01 IC TK11150CSCL-G
IC708 6-806-298-01 IC MB95F108ASPFV-GE1-H0601
IC4502 6-703-589-01 IC SN74LVC1G125DCKR
IC4601 6-707-608-01 IC PCM1803DBR
< COIL >
L3601 1-469-555-21 INDUCTOR 10uH
L4602 1-469-555-21 INDUCTOR 10uH
< LINE FILTER >
* LF701 1-813-308-11 COMMON MODE CHOKE
* LF702 1-813-308-11 COMMON MODE CHOKE
* LF703 1-813-308-11 COMMON MODE CHOKE
* LF704 1-813-308-11 COMMON MODE CHOKE
< TRANSISTOR >
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR RT1N241C-TP-1
Q701 8-729-012-57 TRANSISTOR 2SK1399-T1B
Q702 8-729-012-57 TRANSISTOR 2SK1399-T1B
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-295-91 SHORT CHIP 0
R103 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R125 1-216-805-11 METAL CHIP 47 5% 1/10W
R130 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
R132 1-216-845-11 METAL CHIP 100K 5% 1/10W
R133 1-216-864-11 SHORT CHIP 0
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R138 1-216-809-11 METAL CHIP 100 5% 1/10W
R139 1-216-864-11 SHORT CHIP 0
R140 1-216-833-11 METAL CHIP 10K 5% 1/10W
R141 1-216-855-11 METAL CHIP 680K 5% 1/10W
R142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R143 1-216-805-11 METAL CHIP 47 5% 1/10W
R145 1-216-864-11 SHORT CHIP 0
R146 1-216-805-11 METAL CHIP 47 5% 1/10W
R147 1-216-864-11 SHORT CHIP 0
R148 1-216-864-11 SHORT CHIP 0
R151 1-216-833-11 METAL CHIP 10K 5% 1/10W
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-864-11 SHORT CHIP 0
R154 1-216-864-11 SHORT CHIP 0
R155 1-216-864-11 SHORT CHIP 0
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R159 1-216-805-11 METAL CHIP 47 5% 1/10W
R160 1-216-805-11 METAL CHIP 47 5% 1/10W
R161 1-216-805-11 METAL CHIP 47 5% 1/10W
R162 1-216-864-11 SHORT CHIP 0
R163 1-469-118-21 FERRITE, EMI (SMD) (1608)
R164 1-216-864-11 SHORT CHIP 0
R165 1-469-118-21 FERRITE, EMI (SMD) (1608)
R166 1-216-864-11 SHORT CHIP 0
R167 1-469-118-21 FERRITE, EMI (SMD) (1608)
R169 1-216-864-11 SHORT CHIP 0
R170 1-216-833-11 METAL CHIP 10K 5% 1/10W
R171 1-216-809-11 METAL CHIP 100 5% 1/10W
R172 1-216-864-11 SHORT CHIP 0
DMB12
✩ New part of EEP ROM (IC103, IC706) on the DMB12 board cannot be used.
Therefore, if the mounted DMB12 board (A-1154-449-A, etc.) is replaced,
exchange new EEP ROM (IC103, IC706) with that used before the
replacement.
