18
HCD-DZ720
3-9. POWER BOARD
6
seven screws
(+BV 3
×
8)
When re-assembling, attach the
heat radiation sheets on the
chassis, and then install the
POWER board.
radiation sheets
5
connector
(CN901)
4
connector
(CN3002)
3
connector
(CN506)
7
POWER board
1
two screws
(+BVTP 3
×
8)
2
cover (top)
When re-assembling, leave 30 mm between
harnesses A and B for safety.
harnesses A
harnesses B
clamp
30mm
1
two screws
(+BVTP 3
×
8)
qs
DVD mechanism deck
(CDM85-DVBU102)
9
cover (MD)
2
cover (top)
6
sheet
7
Remove the wire and harness.
q;
three screws (+BV 3
×
6)
8
three screws (+BV 3
×
6)
3
wire (flat type) 24
core
(CN101)
5
wire (flat type) 5
core
(CN202)
qa
wire (flat type) 5
core
4
connector (CN201)
3-10. DVD MECHANISM DECK (CDM85-DVBU102)
