Sony HCD-DZ720 [86/92] Hcd dz720
![Sony HCD-DZ720 [86/92] Hcd dz720](/views2/1793005/page86/bg56.png)
86
HCD-DZ720
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< SHORT >
JC504 1-216-864-11 SHORT CHIP 0
JC521 1-216-864-11 SHORT CHIP 0 (SP)
JC522 1-216-864-11 SHORT CHIP 0 (E3)
JC523 1-216-864-11 SHORT CHIP 0 (AUS)
JC526 1-216-864-11 SHORT CHIP 0 (KR)
< COIL >
L3000 1-469-527-91 INDUCTOR 47uH
L3051 1-414-754-11 INDUCTOR 10uH
L3052 1-414-754-11 INDUCTOR 10uH
L3053 1-414-754-11 INDUCTOR 10uH
L3054 1-412-939-11 INDUCTOR 1uH
L3111 1-456-680-11 INDUCTOR 10uH
L3112 1-456-680-11 INDUCTOR 10uH
L3151 1-456-680-11 INDUCTOR 10uH
L3152 1-456-680-11 INDUCTOR 10uH
L3201 1-456-680-11 INDUCTOR 10uH
L3202 1-456-680-11 INDUCTOR 10uH
L3251 1-456-680-11 INDUCTOR 10uH
L3252 1-456-680-11 INDUCTOR 10uH
L3301 1-456-680-11 INDUCTOR 10uH
L3302 1-456-680-11 INDUCTOR 10uH
L3401 1-456-680-11 INDUCTOR 10uH
L3402 1-456-680-11 INDUCTOR 10uH
L3501 1-456-680-11 INDUCTOR 10uH
L3502 1-456-680-11 INDUCTOR 10uH
< TRANSISTOR >
Q503 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q504 6-550-718-01 TRANSISTOR RSR025N03TL
Q3000 8-729-142-48 TRANSISTOR 2SD1616-TP-LK
Q3001 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q3002 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q3081 8-729-027-23 TRANSISTOR RT1P141C-TP-1
Q3101 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3102 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3151 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3152 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3201 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3202 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3251 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3252 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3301 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3302 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3401 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3402 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3551 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R502 1-216-833-11 METAL CHIP 10K 5% 1/10W
R503 1-216-833-11 METAL CHIP 10K 5% 1/10W
R504 1-216-821-11 METAL CHIP 1K 5% 1/10W
(SP)
R504 1-216-833-11 METAL CHIP 10K 5% 1/10W
(E3)
R504 1-216-835-11 METAL CHIP 15K 5% 1/10W
(AUS)
R504 1-216-841-11 METAL CHIP 47K 5% 1/10W
(KR)
R505 1-216-841-11 METAL CHIP 47K 5% 1/10W
R506 1-216-835-11 METAL CHIP 15K 5% 1/10W
(KR)
R506 1-216-841-11 METAL CHIP 47K 5% 1/10W
(E3, AUS)
R507 1-216-837-11 METAL CHIP 22K 5% 1/10W
R508 1-216-821-11 METAL CHIP 1K 5% 1/10W
R509 1-216-809-11 METAL CHIP 100 5% 1/10W
R510 1-216-833-11 METAL CHIP 10K 5% 1/10W
R511 1-216-809-11 METAL CHIP 100 5% 1/10W
R512 1-216-833-11 METAL CHIP 10K 5% 1/10W
R513 1-216-809-11 METAL CHIP 100 5% 1/10W
R514 1-216-833-11 METAL CHIP 10K 5% 1/10W
R515 1-216-821-11 METAL CHIP 1K 5% 1/10W
R516 1-216-821-11 METAL CHIP 1K 5% 1/10W
R517 1-216-809-11 METAL CHIP 100 5% 1/10W
R518 1-216-809-11 METAL CHIP 100 5% 1/10W
R519 1-216-833-11 METAL CHIP 10K 5% 1/10W
R520 1-216-833-11 METAL CHIP 10K 5% 1/10W
R524 1-216-833-11 METAL CHIP 10K 5% 1/10W
R526 1-216-821-11 METAL CHIP 1K 5% 1/10W
R527 1-216-833-11 METAL CHIP 10K 5% 1/10W
R528 1-216-833-11 METAL CHIP 10K 5% 1/10W
R529 1-216-821-11 METAL CHIP 1K 5% 1/10W
R530 1-216-809-11 METAL CHIP 100 5% 1/10W
R531 1-216-833-11 METAL CHIP 10K 5% 1/10W
R532 1-216-821-11 METAL CHIP 1K 5% 1/10W
R533 1-216-809-11 METAL CHIP 100 5% 1/10W
R534 1-216-833-11 METAL CHIP 10K 5% 1/10W
R535 1-216-809-11 METAL CHIP 100 5% 1/10W
R536 1-216-864-11 SHORT CHIP 0
R539 1-216-833-11 METAL CHIP 10K 5% 1/10W
R540 1-216-833-11 METAL CHIP 10K 5% 1/10W
R541 1-216-833-11 METAL CHIP 10K 5% 1/10W
R543 1-216-833-11 METAL CHIP 10K 5% 1/10W
R545 1-216-833-11 METAL CHIP 10K 5% 1/10W
R546 1-216-833-11 METAL CHIP 10K 5% 1/10W
R549 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R550 1-216-821-11 METAL CHIP 1K 5% 1/10W
R552 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R554 1-216-833-11 METAL CHIP 10K 5% 1/10W
R556 1-216-841-11 METAL CHIP 47K 5% 1/10W
R557 1-216-841-11 METAL CHIP 47K 5% 1/10W
R558 1-216-833-11 METAL CHIP 10K 5% 1/10W
R559 1-216-833-11 METAL CHIP 10K 5% 1/10W
R560 1-216-833-11 METAL CHIP 10K 5% 1/10W
R561 1-216-845-11 METAL CHIP 100K 5% 1/10W
R562 1-216-841-11 METAL CHIP 47K 5% 1/10W
R563 1-216-833-11 METAL CHIP 10K 5% 1/10W
R564 1-216-809-11 METAL CHIP 100 5% 1/10W
R565 1-216-809-11 METAL CHIP 100 5% 1/10W
R566 1-216-809-11 METAL CHIP 100 5% 1/10W
R567 1-216-809-11 METAL CHIP 100 5% 1/10W
R568 1-216-809-11 METAL CHIP 100 5% 1/10W
R569 1-216-809-11 METAL CHIP 100 5% 1/10W
MAIN
