Sony HCD-DZ720 [85/92] Hcd dz720
![Sony HCD-DZ720 [85/92] Hcd dz720](/views2/1793005/page85/bg55.png)
85
HCD-DZ720
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C3417 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3418 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3419 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3420 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3421 1-117-370-11 CERAMIC CHIP 10uF 10V
C3422 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3423 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3500 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C3503 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C3504 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3505 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C3506 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C3507 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C3508 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C3509 1-112-246-11 ELECT 100uF 20% 35V
C3512 1-112-246-11 ELECT 100uF 20% 35V
C3513 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C3514 1-136-177-00 FILM 1uF 5% 50V
C3515 1-136-177-00 FILM 1uF 5% 50V
C3516 1-112-831-11 ELECT 2200uF 20% 35V
C3517 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3518 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3519 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3520 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3551 1-126-960-11 ELECT 1uF 20% 50V
C3552 1-126-964-11 ELECT 10uF 20% 50V
C3555 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN501 1-793-991-11 CONNECTOR, FFC/FPC 23P
CN502 1-506-469-11 PIN, CONNECTOR 4P
CN503 1-784-368-11 CONNECTOR, FFC/FPC 9P
CN504 1-784-370-21 CONNECTOR, FFC/FPC 11P
* CN506 1-564-714-11 PIN, CONNECTOR (SMALL TYPE) 12P
CN601 1-784-376-11 CONNECTOR, FFC/FPC 17P
CN701 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN3000 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
CN3001 1-506-469-11 PIN, CONNECTOR 4P
CN3002 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< DIODE >
D501 6-501-193-01 DIODE 1SS355WTE-17
D502 6-501-193-01 DIODE 1SS355WTE-17
D504 6-501-193-01 DIODE 1SS355WTE-17
D3071 6-501-193-01 DIODE 1SS355WTE-17
D3072 6-501-193-01 DIODE 1SS355WTE-17
D3073 6-501-193-01 DIODE 1SS355WTE-17
D3111 6-500-260-01 DIODE P6SMB39AT3
D3112 6-500-260-01 DIODE P6SMB39AT3
D3151 6-500-260-01 DIODE P6SMB39AT3
D3152 6-500-260-01 DIODE P6SMB39AT3
D3201 6-500-260-01 DIODE P6SMB39AT3
D3202 6-500-260-01 DIODE P6SMB39AT3
D3251 6-500-260-01 DIODE P6SMB39AT3
D3252 6-500-260-01 DIODE P6SMB39AT3
D3301 6-500-260-01 DIODE P6SMB39AT3
D3302 6-500-260-01 DIODE P6SMB39AT3
D3401 6-500-260-01 DIODE P6SMB39AT3
D3402 6-500-260-01 DIODE P6SMB39AT3
D3501 6-500-260-01 DIODE P6SMB39AT3
D3502 6-500-260-01 DIODE P6SMB39AT3
D3551 6-501-193-01 DIODE 1SS355WTE-17
D3552 6-501-193-01 DIODE 1SS355WTE-17
< GROUND TERMINAL BOARD >
EB501 1-537-770-21 TERMINAL BOARD, GROUND
EB505 1-537-770-21 TERMINAL BOARD, GROUND
EB701 1-537-770-21 TERMINAL BOARD, GROUND
EB702 1-537-770-21 TERMINAL BOARD, GROUND
EB703 1-537-770-21 TERMINAL BOARD, GROUND
EB3001 1-537-770-21 TERMINAL BOARD, GROUND
EB3002 1-537-770-21 TERMINAL BOARD, GROUND
EB3003 1-537-770-21 TERMINAL BOARD, GROUND
EB3004 1-537-770-21 TERMINAL BOARD, GROUND
EB3005 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB501 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB502 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB503 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB504 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB505 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB506 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB507 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB508 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB509 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB510 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3051 1-216-295-91 SHORT CHIP 0
< FLUORESCENT INDICATOR >
FL501 1-233-893-21 FILTER, CHIP EMI
FL502 1-234-177-21 FILTER, CHIP EMI
FL503 1-234-177-21 FILTER, CHIP EMI
< IC >
IC501 6-806-589-01 IC M30622MEP-A76FPU0
IC502 6-702-302-01 IC TK11133CSCL-G
IC503 6-708-922-01 IC PST3635NR
IC504 6-709-034-01 IC NJM2887DL3 (TE2)
IC3001 8-759-710-97 IC NJM4565M (TE2)
IC3003 8-759-680-48 IC TC7WH157FK (TE85R)
IC3010 6-707-939-01 IC CXD9843AR
IC3020 6-707-939-01 IC CXD9843AR
IC3030 6-707-939-01 IC CXD9843AR
IC3050 6-702-300-01 IC TK11118CSCL-G
IC3051 8-759-649-50 IC SN74AHC1GU04DCKR
IC3100 6-708-921-01 IC CXD9883M
IC3150 6-708-921-01 IC CXD9883M
IC3200 6-708-921-01 IC CXD9883M
IC3250 6-708-921-01 IC CXD9883M
IC3300 6-708-921-01 IC CXD9883M
IC3400 6-708-921-01 IC CXD9883M
IC3500 6-708-921-01 IC CXD9883M
MAIN
