![Sony HCD-DZ720 [87/92] Hcd dz720](/views2/1793005/page87/bg57.png)
87
HCD-DZ720
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R572 1-218-751-11 METAL CHIP 300K 5% 1/10W
R573 1-216-845-11 METAL CHIP 100K 5% 1/10W
R575 1-216-821-11 METAL CHIP 1K 5% 1/10W
R576 1-216-821-11 METAL CHIP 1K 5% 1/10W
R577 1-216-841-11 METAL CHIP 47K 5% 1/10W
R578 1-216-809-11 METAL CHIP 100 5% 1/10W
R579 1-216-809-11 METAL CHIP 100 5% 1/10W
R580 1-216-809-11 METAL CHIP 100 5% 1/10W
R581 1-216-809-11 METAL CHIP 100 5% 1/10W
R584 1-216-809-11 METAL CHIP 100 5% 1/10W
R585 1-216-809-11 METAL CHIP 100 5% 1/10W
R586 1-216-809-11 METAL CHIP 100 5% 1/10W
R587 1-216-809-11 METAL CHIP 100 5% 1/10W
R588 1-216-809-11 METAL CHIP 100 5% 1/10W
R589 1-216-809-11 METAL CHIP 100 5% 1/10W
R601 1-216-864-11 SHORT CHIP 0
R604 1-216-809-11 METAL CHIP 100 5% 1/10W
R605 1-216-809-11 METAL CHIP 100 5% 1/10W
R606 1-216-809-11 METAL CHIP 100 5% 1/10W
R607 1-216-809-11 METAL CHIP 100 5% 1/10W
R608 1-216-809-11 METAL CHIP 100 5% 1/10W
R609 1-216-809-11 METAL CHIP 100 5% 1/10W
R610 1-216-809-11 METAL CHIP 100 5% 1/10W
R611 1-216-809-11 METAL CHIP 100 5% 1/10W
R612 1-216-809-11 METAL CHIP 100 5% 1/10W
R613 1-216-809-11 METAL CHIP 100 5% 1/10W
R614 1-216-809-11 METAL CHIP 100 5% 1/10W
R691 1-216-864-11 SHORT CHIP 0
R692 1-216-864-11 SHORT CHIP 0
R693 1-216-864-11 SHORT CHIP 0
R694 1-216-864-11 SHORT CHIP 0
R695 1-216-864-11 SHORT CHIP 0
R696 1-216-864-11 SHORT CHIP 0
R701 1-216-813-11 METAL CHIP 220 5% 1/10W
R702 1-216-864-11 SHORT CHIP 0
R3001 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3002 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3003 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3004 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R3006 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3011 1-216-817-11 METAL CHIP 470 5% 1/10W
R3012 1-216-817-11 METAL CHIP 470 5% 1/10W
R3013 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3014 1-216-809-11 METAL CHIP 100 5% 1/10W
R3015 1-216-809-11 METAL CHIP 100 5% 1/10W
R3017 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3021 1-216-817-11 METAL CHIP 470 5% 1/10W
R3022 1-216-817-11 METAL CHIP 470 5% 1/10W
R3023 1-216-809-11 METAL CHIP 100 5% 1/10W
R3024 1-216-809-11 METAL CHIP 100 5% 1/10W
R3026 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3031 1-216-817-11 METAL CHIP 470 5% 1/10W
R3032 1-216-817-11 METAL CHIP 470 5% 1/10W
R3033 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3034 1-216-809-11 METAL CHIP 100 5% 1/10W
R3035 1-216-809-11 METAL CHIP 100 5% 1/10W
R3037 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3050 1-216-864-11 SHORT CHIP 0
R3052 1-216-857-11 METAL CHIP 1M 5% 1/10W
R3053 1-216-809-11 METAL CHIP 100 5% 1/10W
R3054 1-216-801-11 METAL CHIP 22 5% 1/10W
R3055 1-216-809-11 METAL CHIP 100 5% 1/10W
R3057 1-216-809-11 METAL CHIP 100 5% 1/10W
R3059 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3060 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3061 1-216-864-11 SHORT CHIP 0
R3062 1-216-809-11 METAL CHIP 100 5% 1/10W
R3063 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3064 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3065 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3066 1-216-809-11 METAL CHIP 100 5% 1/10W
R3067 1-216-809-11 METAL CHIP 100 5% 1/10W
R3068 1-216-809-11 METAL CHIP 100 5% 1/10W
R3069 1-216-809-11 METAL CHIP 100 5% 1/10W
R3070 1-216-809-11 METAL CHIP 100 5% 1/10W
R3071 1-216-809-11 METAL CHIP 100 5% 1/10W
R3072 1-216-809-11 METAL CHIP 100 5% 1/10W
R3073 1-216-809-11 METAL CHIP 100 5% 1/10W
R3075 1-216-809-11 METAL CHIP 100 5% 1/10W
R3076 1-216-809-11 METAL CHIP 100 5% 1/10W
R3077 1-216-809-11 METAL CHIP 100 5% 1/10W
R3078 1-216-809-11 METAL CHIP 100 5% 1/10W
R3079 1-216-809-11 METAL CHIP 100 5% 1/10W
R3080 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3085 1-216-839-11 METAL CHIP 33K 5% 1/10W
R3086 1-216-839-11 METAL CHIP 33K 5% 1/10W
R3087 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3088 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3089 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3090 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3091 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3092 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3093 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3094 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3095 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3096 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3097 1-216-809-11 METAL CHIP 100 5% 1/10W
R3098 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3099 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3101 1-216-809-11 METAL CHIP 100 5% 1/10W
R3102 1-216-809-11 METAL CHIP 100 5% 1/10W
R3103 1-216-797-11 METAL CHIP 10 5% 1/10W
R3104 1-216-864-11 SHORT CHIP 0
R3107 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3115 1-216-797-11 METAL CHIP 10 5% 1/10W
R3116 1-216-797-11 METAL CHIP 10 5% 1/10W
R3119 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3120 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3121 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3124 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3125 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3126 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3127 1-216-845-11 METAL CHIP 100K 5% 1/10W
