![Sony HCD-DZ720 [81/92] Hcd dz720](/views2/1793005/page81/bg51.png)
81
HCD-DZ720
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C361 1-104-662-91 ELECT 22uF 20% 25V
C362 1-104-662-91 ELECT 22uF 20% 25V
C364 1-126-960-11 ELECT 1uF 20% 50V
C365 1-104-662-91 ELECT 22uF 20% 25V
C366 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C389 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C390 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN201 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN301 1-793-806-51 CONNECTOR, FFC/FPC 17P
CN302 1-785-317-11 PIN, CONNECTOR (STRAIGHT) 5P
CN303 1-568-828-11 CONNECTOR, FFC 9P
CN304 1-779-542-21 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< DIODE >
D280 8-719-988-61 DIODE 1SS355TE-17
D281 8-719-988-61 DIODE 1SS355TE-17
D300 8-719-058-24 DIODE RB501V-40TE-17
< IC >
IC201 6-705-602-01 IC MM1623BFBE
IC202 6-703-622-01 IC MM1508XNRE
IC300 6-703-550-01 IC TA7809LS
IC350 8-759-385-76 IC MC14052 BDR2
IC360 8-759-100-96 IC NJM4558M-TE2
< JACK >
J201 1-780-211-11 TERMINAL BOARD (S TERMINAL+1P)
(S VIDEO (DVD ONLY))(VIDEO)(MONITOR OUT)
J203 1-819-063-11 JACK, PIN (6P)(Y, Pb/Cb, Pr/Cr (DVD ONLY))
(COMPONENT VIDEO OUT)(R, L, VIDEO IN)(TV VCR)
< COIL >
L201 1-469-525-91 INDUCTOR 10uH
L221 1-469-525-91 INDUCTOR 10uH
L300 1-469-525-91 INDUCTOR 10uH
L350 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q300 8-729-027-23 TRANSISTOR RT1P141C-TP-1
Q310 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q320 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q395 8-729-027-52 TRANSISTOR RT1N241C-TP-1
Q396 8-729-027-52 TRANSISTOR RT1N241C-TP-1
< RESISTOR >
R210 1-218-285-11 METAL CHIP 75 5% 1/10W
R211 1-218-285-11 METAL CHIP 75 5% 1/10W
R212 1-218-285-11 METAL CHIP 75 5% 1/10W
R213 1-218-285-11 METAL CHIP 75 5% 1/10W
R214 1-218-285-11 METAL CHIP 75 5% 1/10W
R215 1-218-285-11 METAL CHIP 75 5% 1/10W
R216 1-218-285-11 METAL CHIP 75 5% 1/10W
R217 1-216-833-11 METAL CHIP 10K 5% 1/10W
R224 1-218-285-11 METAL CHIP 75 5% 1/10W
R225 1-218-285-11 METAL CHIP 75 5% 1/10W
R227 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R228 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R229 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R230 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R231 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R232 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R286 1-216-821-11 METAL CHIP 1K 5% 1/10W
R301 1-216-821-11 METAL CHIP 1K 5% 1/10W
R302 1-216-821-11 METAL CHIP 1K 5% 1/10W
R310 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R311 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R312 1-216-833-11 METAL CHIP 10K 5% 1/10W
R313 1-216-841-11 METAL CHIP 47K 5% 1/10W
R314 1-216-841-11 METAL CHIP 47K 5% 1/10W
R320 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R322 1-216-833-11 METAL CHIP 10K 5% 1/10W
R323 1-216-841-11 METAL CHIP 47K 5% 1/10W
R324 1-216-841-11 METAL CHIP 47K 5% 1/10W
R331 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R332 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R335 1-216-841-11 METAL CHIP 47K 5% 1/10W
R336 1-216-841-11 METAL CHIP 47K 5% 1/10W
R341 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R342 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R345 1-216-841-11 METAL CHIP 47K 5% 1/10W
R346 1-216-841-11 METAL CHIP 47K 5% 1/10W
R351 1-216-845-11 METAL CHIP 100K 5% 1/10W
R352 1-216-845-11 METAL CHIP 100K 5% 1/10W
R353 1-216-841-11 METAL CHIP 47K 5% 1/10W
R355 1-216-817-11 METAL CHIP 470 5% 1/10W
R356 1-216-833-11 METAL CHIP 10K 5% 1/10W
R357 1-216-821-11 METAL CHIP 1K 5% 1/10W
R358 1-216-833-11 METAL CHIP 10K 5% 1/10W
R359 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R360 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R361 1-216-845-11 METAL CHIP 100K 5% 1/10W
R362 1-216-845-11 METAL CHIP 100K 5% 1/10W
R363 1-216-841-11 METAL CHIP 47K 5% 1/10W
R365 1-216-817-11 METAL CHIP 470 5% 1/10W
R399 1-216-821-11 METAL CHIP 1K 5% 1/10W
*************************************************************
A-1144-767-A JACK BOARD, COMPLETE
*********************
< CAPACITOR >
C401 1-124-589-11 ELECT 47uF 20% 16V
C403 1-124-584-00 ELECT 100uF 20% 10V
C404 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C405 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C410 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C411 1-126-157-11 ELECT 10uF 20% 16V
C412 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C413 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C420 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C421 1-126-157-11 ELECT 10uF 20% 16V
C422 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C423 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C431 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
JACKIO-S TERMINAL
