![Sony HCD-DZ720 [17/92] 7 dmb12 board](/img/pdf.png)
Sony HCD-DZ720 [17/92] 7 dmb12 board
![Sony HCD-DZ720 [17/92] 7 dmb12 board](/views2/1793005/page17/bg11.png)
17
HCD-DZ720
3-7. DMB12 BOARD
3-8. DC FAN, TUNER UNIT
qa
DMB12 board
0
seven screws (+BV 3
×
6)
9
screw (+B 3
×
6)
5
connector (CN601)
6
wire (flat type)
11core (CN4301)
4
wire (flat type)
24core (CN101)
7
wire (flat type)
5core (CN4302)
8
wire (flat type)
9core (CN4501
)
1
wire (flat type)
11core (CN109)
2
wire (flat type)
5core (CN202)
3
connector (CN201)
7
DC fan
3
tuner unit
4
two screws
(+BVTP 3
×
8
)
5
cover (fan)
1
two screws (+BVTT 3
×
6)
6
two screws
(+BVTT 4
×
8)
2
wire (flat type)
9core
