Sony HCD-DZ720 [83/92] Hcd dz720
![Sony HCD-DZ720 [83/92] Hcd dz720](/views2/1793005/page83/bg53.png)
83
HCD-DZ720
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< SWITCH >
S800 1-418-725-51 ENCODER, ROTARY (12 TYPE)
(VOLUME – +)
S802 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S803 1-762-875-21 SWITCH, KEYBOARD (.)
S804 1-762-875-21 SWITCH, KEYBOARD (X)
S805 1-762-875-21 SWITCH, KEYBOARD (x)
S806 1-762-875-21 SWITCH, KEYBOARD (>)
S807 1-762-875-21 SWITCH, KEYBOARD (A)
S808 1-762-875-21 SWITCH, KEYBOARD (H)
*************************************************************
A-1154-444-A MAIN BOARD, COMPLETE (SP)
A-1154-472-A MAIN BOARD, COMPLETE (KR)
A-1174-776-A MAIN BOARD, COMPLETE (E3)
A-1174-786-A MAIN BOARD, COMPLETE (AUS)
*********************
< CAPACITOR >
C501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C506 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C509 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C511 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C515 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C516 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C517 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C519 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C520 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C521 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C522 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C523 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C524 1-126-947-11 ELECT 47uF 20% 16V
C525 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C526 1-104-658-91 ELECT 100uF 20% 10V
C527 1-104-656-11 ELECT 2200uF 20% 6.3V
C528 1-104-658-91 ELECT 100uF 20% 10V
C529 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C531 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C532 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C533 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C534 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C535 1-126-947-11 ELECT 47uF 20% 16V
C536 1-126-947-11 ELECT 47uF 20% 16V
C537 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C538 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3000 1-125-972-91 ELECT 100uF 20% 16V
C3001 1-126-947-11 ELECT 47uF 20% 16V
C3002 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3011 1-126-947-11 ELECT 47uF 20% 16V
C3012 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3013 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3014 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3015 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3016 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3017 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3018 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3019 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3020 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3021 1-126-947-11 ELECT 47uF 20% 16V
C3022 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3023 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3024 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3025 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3026 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3027 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3028 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3029 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3030 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3031 1-126-947-11 ELECT 47uF 20% 16V
C3032 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3033 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3034 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3035 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3036 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3037 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3038 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3039 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3040 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3051 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3052 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3053 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3054 1-126-933-11 ELECT 100uF 20% 16V
C3055 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3056 1-126-923-91 ELECT 220uF 20% 10V
C3057 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3058 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C3059 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3060 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C3067 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3068 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3069 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3070 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3071 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3072 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3073 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3075 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C3081 1-126-925-91 ELECT 470uF 20% 10V
C3082 1-126-925-91 ELECT 470uF 20% 10V
C3083 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3084 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3085 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3086 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3087 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3088 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3089 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3090 1-104-658-91 ELECT 100uF 20% 10V
C3091 1-126-934-11 ELECT 220uF 20% 16V
C3092 1-164-156-11 CERAMIC CHIP 0.1uF 25V
MAINJACK
