ATEN Control System User Manual
20
No. Component Description
1 power socket Plugs in the power cord from an AC power source.
2 power switch Powers the unit on or off.
3 12 V DC output
ports
1 / 4 DC output port(s) providing a total output of 12 V DC, 1
/ 2 A from the Control Box.
4 relay channels 4 / 8 channels; normally open, isolated relays with a contact
rating of 24 V DC, 2 A max.
5 I/O channels 2 / 4 / 8 channels that can be configured as digital inputs or
outputs, with the first pin being ground and the rest being
number pins.
Digital Input:
VDC Mode: 0 - 24 V DC; programmable range of 1 -
24 V DC
Dry Contact Mode: Pull-up 2k Ω to +12 V DC
Digital Output: 300 mA sink from 24 V DC
6 IR / serial ports 2 / 4 / 8 IR ports that can also be configured as RS-232 TX
ports. pin 1: Signal / pin 2: Ground.
7 RS-232/422/
485 serial ports
1 / 2 5-pin RS-232/422/485 serial ports by pin assignment.
8 RS-232 serial
ports
1 / 4 / 6 3-pin RS-232 serial ports with Tx, Rx and GND.
9 grounding
terminal
Connects to the grounding wire.
10 LAN
Connects the unit to the corporate LAN for remote
access and centralized management by ATEN Unizon.
Default network settings when no dynamic IP address is
assigned by a DHCP server, after 30 seconds:
VK2200 / VK1200
IP: 192.168.1.60
mask: 255.255.255.0
VK2100A / VK1100A / VK2100 / VK1100
IP: 192.168.0.60
mask: 255.255.255.0
