Chapter 2. Hardware Setup and Panel Oper-
21
11 Control LAN
Connects the unit to a secure subnetwork, separate
from the corporate LAN, for managing IP devices and
configuration by the ATEN Configurator VK6000, as well
as for remote control by ATEN Keypads, Touch Panel or
the ATEN Control System app on mobile devices.
Default network settings when no dynamic IP address is
assigned by a DHCP server, after 30 seconds:
IP: 192.168.0.60
mask: 255.255.255.0
Supports DHCP server
