2. PRODUCT SPECIFICATIONS
Items Specification
Model
RB37A**9** RB37A**5** RB37A**0** RB37A**1**(CIS)
Room Temperature Sensor Components
Freezer
Model
Temperature
Selection
ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃)
Thermistor
-23℃ -21 -25 -21 -25 -21 -25 -21 -25
-19℃ -18 -22 -18 -22 -18 -22 -18 -22
-15℃ -12.5 -16.5 -12.5 -16.5 -12.5 -16.5 -12.5 -16.5
Refrigerator
Model
Temperature
Selection
ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃)
Thermistor
1℃ -1 3 -1 3 -1 3 -1 3
3℃ 0.5 4.5 0.5 4.5 0.5 4.5 0.5 4.5
7℃ 4.5 8.5 4.5 8.5 4.5 8.5 4.5 8.5
Defrost Related Components
Defrost Cycle
First Defrost Cycle (Concurrent defrost
of F and F)
6 ± 10 min
Defrost Cycle (FRE) 6~77hr(vary according to the conditions used)
Pause time 5 ± 1 min
Defrost Sensor
Model SENSOR TEMP-F DEF SENSOR
SPEC 5.39 or 5.49 Kohm at 23℃
Thermal-Fuse
Rated 120V/250V, 15A/10A
Operating
temperature
109 ~ 110℃
