Samsung RB37A52N0SA [9/101] Product specifications
![Samsung RB37A52N0SA [9/101] Product specifications](/views2/2003577/page9/bg9.png)
9
2. PRODUCT SPECIFICATIONS
Item SPECIFICATION
Models RB31F****B RB31F***C
RB31FD***D
RB31FW***D
RB31F****D RB29F****B RB29F***C
RB29FD***D
RB29FW***D
RB29F****D
Net
Capacity
Total 304 304 308 310 286 286 288 290
Refrigerator
206 206 210 212 188 188 190 192
Freezer 98 98 98 98 98 98 98 98
Net
dimension
W (mm) 595
D (mm) 664
H (mm) 1850 1780
Rated Voltage and Frequency 230V / 50HZ
Motor Rated
Consumption
Power
C-FAN 12V, 3W - - - 12V, 3W - - -
F-FAN 12V, 2.2W
Electric Heater Rated
Consumption Power
230V, 150W
Kind of Refrigerator INDIRECT COOLING METHOD REFRIGERATOR
Refrigerant/
Refrigerant Amount
R-600a
61 Gr 61 Gr 61 Gr 61 Gr 61 Gr 61 Gr 61 Gr 61 Gr
Freezer Performance 4-STAR
Product Weight 65 kg 65 kg 65 kg 65 kg 63 kg 63 kg 63 kg 63 kg
