3. DISASSEMBLY & REASSEMBLY

PART NAME

FIGURE DESCRIPTION

Removing

the

Refrigerator

Door

(Reversible)

Remove the freezer door from the Bottom

hinge by carefully lifting the door staright

up.

The door is heavy, be careful not to

injure yourself when removing the

door.

Basic position

Position reversed

Remove the screw on the bottom right

side of the Fridge and Freezer Door

Switch Lever Auto Closer from the right to

the left.

(Lever Auto closer, Screws each one.)

10.

Switch the Position of Cap screw and

Cap.

Be careful not to injure yourself during

operation.

11.

Lay the refrigerator carefully.

Remove the Leg and the Hinge Low.

NOTE

To protect the refrigerator damage,

cut a large section of the cardboard

carton and place it under the

refrigerator.

12.

Assemble the Middle hinge by the

Phillips Head (+) screwdriver.

(Assemble Washer upwardly before

assembling Middle hinge.)

Washer (oponal)
