3. DISASSEMBLY & REASSEMBLY
3-5) Freezer Compartments
PART NAME FIGURE DESCRIPTION
Plastic Drawer
In Freezer
Drawers are designed for storage of meat and dry
foods.
The drawers are located in the lower portion of
the refrigerator.
1. Pull out the drawer as far as it goes.
2. Tilt the drawer up and pull it out until it is
removed.
