4. TROUBLESHOOTING
DATA1.Temp Table
Conversion Table - Temperature/MICOM PORT Voltage/Resistance
SENSOR CHIP : PX41C
℃ ℉ Voltage Ω ℃ ℉ Voltage Ω ℃ ℉ Voltage Ω
-50 -58 4.694 153319 -5 23 3.107 16419 40 104 1.153 2997
-49 -56.2 4.677 144794 -4 24.8 3.057 15731 41 105.8 1.124 2899
-48 -54.4 4.659 136798 -3 26.6 3.006 15076 42 107.6 1.095 2805
-47 -52.6 4.641 129294 -2 28.4 2.955 14452 43 109.4 1.068 2714
-46 -50.8 4.622 122248 -1 30.2 2.904 13857 44 111.2 1.040 2627
-45 -49 4.602 115631 0 32 2.853 13290 45 113 1.014 2543
-44 -47.2 4.581 109413 1 33.8 2.802 12749 46 114.8 0.988 2462
-43 -45.4 4.560 103569 2 35.6 2.751 12233 47 116.6 0.963 2384
-42 -43.6 4.537 98073 3 37.4 2.700 11741 48 118.4 0.938 2309
-41 -41.8 4.514 92903 4 39.2 2.649 11271 49 120.2 0.914 2237
-40 -40
4.490 88037 5 41 2.599 10823 50 122 0.891 2167
-39 -38.2 4.465 83456 6 42.8 2.548 10395 51 123.8 0.868 2100
-38 -36.4 4.439 79142 7 44.6 2.498 9986 52 125.6 0.846 2036
-37 -34.6 4.412 75077 8 46.4 2.449 9596 53 127.4 0.824 1973
-36 -32.8 4.385 71246 9 48.2 2.399 9223 54 129.2 0.803 1913
-35 -31 4.356 67634 10 50 2.350 8867 55 131 0.783 1855
-34 -29.2 4.326 64227 11 51.8 2.301 8526 56 132.8 0.762 1799
-33 -27.4 4.296 61012 12 53.6 2.253 8200 57 134.6 0.743 1745
-32 -25.6 4.264 57977 13 55.4 2.205 7888 58 136.4 0.724 1693
-31 -23.8 4.232 55112 14 57.2 2.158 7590 59 138.2 0.706 1642
-30 -22 4.199 52406 15 59 2.111 7305 60 140 0.688 1594
-29 -20.2 4.165 49848
16 60.8 2.064 7032 61 141.8 0.670 1547
-28 -18.4 4.129 47431 17 62.6 2.019 6771 62 143.6 0.653 1502
-27 -16.6 4.093 45146 18 64.4 1.974 6521 63 145.4 0.636 1458
-26 -14.8 4.056 42984 19 66.2 1.929 6281 64 147.2 0.620 1416
-25 -13 4.018 40938 20 68 1.885 6052 65 149 0.604 1375
-24 -11.2 3.980 39002 21 69.8 1.842 5832 66 150.8 0.589 1335
-23 -9.4 3.940 37169 22 71.6 1.799 5621 67 152.6 0.574 1297
-22 -7.6 3.899 35433 23 73.4 1.757 5419 68 154.4 0.560 1260
-21 -5.8 3.858 33788 24 75.2 1.716 5225 69 156.2 0.546 1225
-20 -4 3.816 32230 25 77 1.675 5039 70 158 0.532 1190
-19 -2.2 3.773 30752 26 78.8 1.636 4861 71 159.8 0.519 1157
-18 -0.4 3.729 29350 27 80.6
1.596 4690 72 161.6 0.506 1125
-17 1.4 3.685 28021 28 82.4 1.558 4526 73 163.4 0.493 1093
-16 3.2 3.640 26760 29 84.2 1.520 4369 74 165.2 0.481 1063
-15 5 3.594 25562 30 86 1.483 4218 75 167 0.469 1034
-14 6.8 3.548 24425 31 87.8 1.447 4072 76 168.8 0.457 1006
-13 8.6 3.501 23345 32 89.6 1.412 3933 77 170.6 0.446 978
-12 10.4 3.453 22320 33 91.4 1.377 3799 78 172.4 0.435 952
-11 12.2 3.405 21345 34 93.2 1.343 3670 79 174.2 0.424 926
-10 14 3.356 20418 35 95 1.309 3547 80 176 0.414 902
-9 15.8 3.307 19537 36 96.8 1.277 3428 81 177.8 0.404 877
-8 17.6 3.258 18698 37 98.6 1.253 3344 82 179.6 0.394 854
-7 19.4 3.208 17901 38 100.4 1.213 3204
83 181.4 0.384 832
-6 21.2 3.158 17142 39 102.2 1.183 3098 84 183.2 0.375 810
