4. TROUBLESHOOTING
2) Fridge Temp Shift Table
Setting Item Display Off Option
Option Item
Location : Fridge Temp Display
16
Setting Value
Option Value
Fridge
Temp Display Panel
Set Value
0
Display Off in 10
seconds after
feeding the Key
value
1
Display On mode
persists
2
Display On mode
persists
Ex) When set Fridge Value “2”
