Samsung RB37A52N0SA [47/101] Troubleshooting
![Samsung RB37A52N0SA [47/101] Troubleshooting](/views2/2003577/page47/bg2f.png)
47
4. TROUBLESHOOTING
※ Self-Diagnosis Check List
NO Defect Item Description
ERROR CODE
(Temp Display)
1 F-DEF ERROR Freezer Room Defrost Heater Error Freezer "-23℃" LED LAMP
2 EXT - SENSOR External SENSOR Error Freezer "-21℃" LED LAMP
3 F - SENSOR Freezer Room SENSOR Error Freezer "-19℃" LED LAMP
4 R - SENSOR Fridge Room SENSOR Error Freezer "-17℃" LED LAMP
5 F - DEF - SENSOR Freezer Defrost SENSOR Error Freezer "-15℃" LED LAMP
6 R - DEF - SENSOR Fridge Defrost SENSOR Error "Vacation" LED LAMP
7 F_FAN-SENSOR Freezer Defrost SENSOR Error Fridge "1℃" LED LAMP
8 C-FAN ERROR Machine Room Fan Motor Error Fridge "2℃" LED LAMP
9 R-FAN ERROR Fridge Room Fan Motor Error "Power Freezer" LED LAMP
10
COMP Run failure ERROR COMP Run failure ERROR
Fridge "3℃" LED LAMP
COMP IPM FAULT ERROR COMP IPM FAULT ERROR
COMP ABNORMAL CURRENT
ERROR
COMP Location detection ERROR
COMP MOTOR RESTRICTION
ERROR
COMP MOTOR Bind ERROR
COMP Low Voltage ERROR COMP Low Voltage ERROR
COMP Over Voltage ERROR COMP Over Voltage ERROR
