3. DISASSEMBLY & REASSEMBLY
PART NAME FIGURE DESCRIPTION
Removing
the
Refrigerator
Door
(Reversible)
24. Remove the Cap Handle and the Screws
by Flat-Head (-) screwdriver.
Remove the Cap by Flat-Head (-)
screwdriver and assemble the Handle and
Cap-Handle.
Be careful the Scratch, when
disassembling the Cap.
25. Assemble the Cap.
