14
2. PRODUCT SPECIFICATIONS
Items Specification
Model RB31FE***
RB31FE***
RB30FE***
RB31FD***
RB31FW***
RB31F****
RB32F****
RB29F****
RB29F****
RB28F****
RB29FD***
RB29FW***
RB29F****
RB28F****
Room Temperature Sensor Components
Freezer
Model
Temperature
Selection
ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃)
Thermistor
-23℃ -21.0 -25.0 -21.0 -25.0 -21.0 -25.0 -21.0 -25.0 -21.0 -25.0 -21.0 -25.0 -21.0 -25.0 -21.0 -25.0
-19℃ -18.0 -22.0 -18.0 -22.0 -18.0 -22.0 -18.0 -22.0 -18.0 -22.0 -18.0 -22.0 -18.0 -22.0 -18.0 -22.0
-15℃ -12.5 -16.5 -12.5 -16.5 -12.5 -16.5 -12.5 -16.5 -12.5 -16.5 -12.5 -16.5 -12.5 -16.5 -12.5 -16.5
Refrigerator
Model
Temperature
Selection
ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃) ON(℃) OFF(℃)
Thermistor
1℃ -1.0 3.0 -1.0 3.0 -1.0 3.0 -1.0 3.0 -1.0 3.0 -1.0 3.0 -1.0 3.0 -1.0 3.0
3℃ 0.5 4.5 0.5 4.5 0.5
4.5 0.5 4.5 0.5 4.5 0.5 4.5 0.5 4.5 0.5 4.5
7℃ 4.5 8.5 4.5 8.5 4.5 8.5 4.5 8.5 4.5 8.5 4.5 8.5 4.5 8.5 4.5 8.5
Defrost Related Components
Defrost Cycle
First Defrost Cycle
(Concurrent defrost of F
and F)
6 ± 10 min
Defrost Cycle (FRE) 6 ~ 56hr (vary according to the conditions used)
Pause time 5 ± 1 min
Defrost Sensor
Model SENSOR TEMP-F DEF SENSOR
SPEC 5.39 or 5.49 Kohm at 23℃
Thermal-Fuse
Rated 120V/250V, 15A/10A
Operating
temperature
109~110℃
