Samsung RB37A52N0SA [50/101] Troubleshooting
![Samsung RB37A52N0SA [50/101] Troubleshooting](/views2/2003577/page50/bg32.png)
50
4. TROUBLESHOOTING
※ Load Mode Check List
NO Category Display LED
Description
1 COMP Freezer "-23℃" Indicator LED On LED On when Comp is running
2 F-Defrost HEATER Freezer "-21℃" Indicator LED On
LED On when the Freezer Defrost
Heater is on
3 R-Damper Freezer "-19℃" Indicator LED On
LED On when the Fridge Damper is
open.
4 Overload Conditions Freezer "-17℃" Indicator LED On
LED On when the ambient
temperature is over 34℃
5
Low Temperature
Conditions
Freezer "-15℃" Indicator LED On
LED On when the ambient
temperature is lower than 23℃
6 Demo Mode Fridge "1℃" Indicator LED On
LED On when the unit is on Demo
Mode
7 F-Fan High Fridge "2℃" Indicator LED On LED On when the F-Fan runs High
8 F-Fan Low Fridge "3℃" Indicator LED On LED On when the F-Fan runs Low
9 R-FAN High Vacation" Indicator LED On LED On When the R-Fan runs High
10
R-FAN Low "Power Freezer" Indicator LED On LED On When the R-Fan runs Low
11 C-Fan High Fridge "5℃" Indicator LED On LED On when the C-Fan runs High
12 C-Fan Low Fridge "7℃" Indicator LED On LED On when the C-Fan runs Low
13
Normal Operating
Conditions
Freezer "-15℃","-17℃"LED Off
When the ambient temperature is
between 24℃~33℃
