32
ENGLISH
6. Program indicator
7. ON/OFF/Mode selector button
8. Timer button
9. Open window detection indicator
10. Timer indicator
11. Display
INSTALLATION
Choose a proper place for installation, keep left
and right at least 20 cm distance to any wall.
Drill two holes in the wall at a minimum height
of 1.8 m above the oor. The distance between
the two holes should be according to drawing
B. Insert dowels into the holes. Use screws with
heads that t through the mounting holes of the
base plate of the fan heater. When screwing in the
screws, make sure that they protrude slightly from
the wall so that the unit can be hung properly.
OPERATION
Set up and switch on:
1. Connect the fan heater to the power outlet.
2. Turn on the main power switch of the fan
heater.
3. The fan heater beeps and displays “ ”, which
means it is in standby mode.
CONTROL PANEL OPERATION:
To start the fan heater, press the “ ” button. By
default, the unit starts in fan mode and displays
“--“
Mode selection:
Press the
button (repeatedly) to switch
between the dierent modes…
("--")
High heating power
The heating power is around 2000 W
(2heating indicators light up on the display)
("--")
Low heating power
The heating power is around 1000 W
(1heating indicator lights up on the display)
("
--")
Fan only mode
Only the fan is running, no heating.
Standby mode
(display)
Temperature controlled mode:
Press the [+]/[-] button repeatedly to select the
desired room temperature.
The temperature can be set from 10 to 49°C in 1°C
steps.
In this smart mode the heater will cycle on and o
to maintain the set temperature.
The display shows the set target temperature.
Timer functions:
• Auto-o timer:
When the fan heater is running, press the “
”
button (repeatedly) to set a time after which the
heater turns o automatically.
The timer can be set from 0 to 9 hours in 1h steps.
Selecting 0 deactivates the timer.
• Power-on timer:
When the fan heater is in standby mode, press
the “
” button (repeatedly) to set a power-on
timer. When this timer is set, the display shows the
remaining time in hours until the heater turns on.
The timer can be set from 0 to 12 hours in 1h
steps. Selecting 0 deactivates the timer.
The default temperature setting is 23°C.
Note: When no program has been set, the heater
automatically switches to standby mode after
12hours.
REMOTE CONTROL:
In order to use the fan heater with all its features,
the remote control is required.
Use a CR2025 (3 V) battery for the remote control.
(Fig. C)
1. Turn the fan heater on/o (o=standby)
2. Switches between operating modes
(Fan mode, Low heating power, High heating
power)
3. The timer functions that can be performed
with the remote control are identical to those
on the control panel of the fan heater
4. [+]/[-] buttons
5. OK/conrm button
6. Set current time/day
7. Activates/deactivates “Open window
detection”
8. Activates/deactivates “Program function”
9. Program setting buttons
(see “Program setting sequence”)
Open window detection function:
To activate this function, press the “
” button
while the heater is running. The open window
detection indicator will light up and the display
shows 23°C by default.
Press the [+]/[-] buttons to select the desired room
temperature.
When the ambient temperature drops at least by
5°C within 10 minutes, the fan heater switches to
standby mode after a short time. In this case, the
fan heater must be switched on again manually to
continue operation.
You can deactivate the open window detection by
pressing the “ ” button again.
INSTRUCTION MANUAL
FAN HEATER
This product is only suitable for well
insulated spaces or occasional use.
IMPORTANT SAFETY INSTRUCTIONS
The safety of electrical appliances from FIRST
Austria complies with the recognized technical
directives and legal regulations for safety.
Nevertheless, you and the other users of the
appliance should observe the following:
• Please read these instructions carefully before
using this appliance for the rst time and keep
them for further reference.
• This product has not been designed for any
other uses than those specied in this manual.
• Before connecting the appliance to the power
source, check if the voltage indicated on the
appliance corresponds with the mains voltage
in your home. If this is not the case, contact
your dealer and do not use the appliance.
• If the appliance is grounded (protection class I),
the wall outlet and any extension to which it is
connected must also be grounded.
• The fan heater should be hung on the wall with
the air outlet facing down. Do not hang the
heater upside down.
• Do not operate or place any part of this
appliance on or near any hot surface (such as
gas or electric burner or a heated oven).
• Do not use the product near gas sources or
other ammable materials or objects.
• Keep a safe distance from furniture and other
objects.
• Do not point the fan heater directly at furniture
or other objects.
• The appliance must not be exposed to
dripping or splashing water. Do not place any
water containers (such as vases) next to or on
top of the appliance.
• To protect from electrical hazard, do not
immerse this appliance or cordset in any
liquids.
• If the appliance or the power cord shows any
signs of damage, do not operate it! Take the
product to an authorized and qualied service
center for inspection or repair.
• Do not block or cover the air inlets and outlets
in any way!
• Do not place ammable material (paper, cloth,
etc.) on or near the appliance.
• Make sure the appliance is switched o before
plugging in or unplugging the device.
• This device is intended for home use only, do
not use it commercially.
• Do not use this appliance outdoors.
• Do not leave the appliance unattended while it
is operating.
• Do not use this heater in the immediate
vicinity of a bathtub, a shower or a swimming
pool.
• This appliance heats up during use. To avoid
burns, do not touch hot surfaces.
• Always disconnect the appliance from power
after use, before cleaning and in the event of a
malfunction.
• As long as the appliance is hot, it should be
supervised, even if it is not connected to the
mains. Allow the appliance to cool down fully
before cleaning and storing it.
• Do not pull directly on the power cord, rather
pull on the plug to disconnect the appliance
from the power source.
• The appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the appliance
in a safe way and understand the hazards
involved. Children shall not play with the
appliance. Cleaning and user maintenance
shall not be made by children unless they
are older than 8 and supervised. Keep the
appliance and its cord out of reach of children
less than 8 years.
• We are excluded of liability for all damages that
may arise if the appliance is used for purposes
other than originally intended or if it is used
inappropriately.
• Repairs and other work undertaken on the unit
must only be done by authorised specialist
personnel!
FEATURES
• Electronic room temperature control
• Remote Control
• Timer
• 2 Heating Levels
• Minimum heat output: 1 kW
• Maximum heat output: 2 kW
• Fan only mode (no heating)
• Open window detection
• Programmable week timer
DESCRIPTION: (Fig. A)
1. Main power switch
2. Control panel
3. Heating element
4. Heating power indicator
5. Temperature indicator (°Celsius)
ENGLISH
