00.8
Model R 1150 R
Connection
32 Steering
Handlebars to fork bridge, tightening se-
quence:
1. Front fastener (as viewed in forward
direction of travel) until seated
Nm 21
2. Rear fastener (as viewed in forward
direction of travel)
Nm 21
Handlebar weight to handlebars Nm 21
Pivot screw, handlebar lever Nm 11
(Tuflok Blue thread-locking compound; screw
can be released and tightened a number of
times)
Model R 1150 R
Connection
33 Rear wheel drive
Oil filler plug Nm 23
Oil drain plug Nm 23
Threaded ring Nm 160
(clean thread + Loctite 577)
Hexagon nut, input bevel gear Nm
200
(clean thread + Loctite 2701)
Cover to rear-wheel drive housing Nm 35
Fixed bearing stud bolt, swinging arm to
gearbox
Nm 160
Floating bearing stud bolt, swinging arm to
gearbox
1. initial torque Nm 9
2. slacken
3. final torque Nm 7
Locknut, floating bearing stud bolt,
swinging arm to gearbox
Nm 160
Fixed bearing stud bolt,
swinging arm to rear axle housing
Nm 160
(clean thread + Loctite 2701)
Floating bearing stud bolt,
swinging arm to rear axle housing
1. initial torque Nm 9
2. slacken
3. final torque Nm 7
Locknut, floating bearing stud bolt,
swinging arm to rear axle housing
Nm 160
(clean thread + Loctite 2701)
