00.9
Reaction link to rear wheel drive / gearbox Nm 43
(load approx. 85 kg (187 lbs) onto motorcycle
and tighten loose reaction link)
Spring strut to rear frame Nm 50
Spring strut to rear swinging arm Nm 58
(clean thread + Loctite 243)
Hydraulic spring preload adjuster to foot-
rest plate
Nm 22
Model R 1150 R
Connection
34 Brakes
Brake caliper to fork slider tube, Evo
brakes
Nm 30
Brake caliper to rear wheel drive Nm 40
Brake disc to front wheel Nm 21
(clean thread + Loctite 2701)
Brake disc to rear wheel drive Nm 21
(clean thread + Loctite 2701)
Master cylinder to footrest assembly Nm 9
Footbrake lever to footrest assembly Nm
21
(clean thread + Loctite 2701)
Footbrake-lever stop Nm
9
Ball socket to thrust rod Nm
9
Brake lines/brake hose to brake compo-
nents
Nm
18
Brake hose to bracket Nm
9
Brake hose to brake lever fitting Nm 18
Bracket to front frame Nm 9
Bracket to rear frame Nm 9
(clean thread + Loctite 2701)
Front brake caliper bleed screw Nm
9
Rear brake caliper bleed screw Nm
6
Filler adapter to brake line Nm 18
ABS hydraulic unit to bracket Nm
8
ABS hydraulic unit to battery carrier Nm
8
Model R 1150 R
Connection
33 Rear wheel drive
