00.10
Model R 1150 R
Connection
36 Wheels and tyres
Quick-release axle clamp screws Nm 22
Quick-release axle threaded fastener Nm 30
Rear wheel to rear wheel drive
Hand-tighten wheel studs and tighten in
diagonally opposite sequence
[Integral ABS] Note spacer
Nm 105
Model R 1150 R
Connection
46 Frame
Frame to engine Nm 82
Struts to frame Nm 58
Strut to engine Nm 58
(clean thread + Loctite 2701)
Rear frame to gearbox/engine
to gearbox and footrest plate Nm 42
(clean thread + Loctite 2701)
to engine Nm 42
Carrier plate for main stand to engine, right
M 12 screw Nm 72
(clean thread + Loctite 2701)
Pivot mount to engine, left
M 12 screw Nm 72
(clean thread + Loctite 2701)
M 8 screw Nm 21
Pivot mount of main (centre) stand (stud bolt) Nm 21
(clean thread + Loctite 243)
Pivot mount of main (centre) stand (ma-
chine screw)
Nm 21
Side stand to pivot mount Nm 58
(clean thread + Loctite 2701)
Footrest plate to gearbox Nm 21
Rear footrest plate to rear frame Nm 21
Front mudguard to fork slider tube bridge Nm 6
(Tuflok Blue thread-locking compound; screw
can be released and tightened a number of
times
alternatively: clean thread + Loctite 243)
