00.11
Front and rear sections of front mudguard
to slider tube
Nm 3
(Tuflok Blue thread-locking compound; screw
can be released and tightened a number of
times
alternatively: clean thread + Loctite 243)
Headlight bracket to fork bridge Nm 20
Model R 1150 R
Connection
51 Equipment
Mirrors Nm 15
Ignition/steering lock to fork bridge Nm 20
(micro-encapsulated)
Model R 1150 R
Connection
61 General electrical equipment
Horn to holder Nm 8
(clean thread + Loctite 243)
Ground (earth) strap to engine block Nm 9
Battery carrier to rubber-metal element Nm 8
Model R 1150 R
Connection
46 Frame
