Ethernet Switch CLI Reference Guide
103
CHAPTER 26
IP Commands
Use these commands to configure the management port IP address, default domain name
server and to look at IP domains.
" See Chapter 55 on page 179 for static route commands.
" See Chapter 27 on page 107 for IP source binding commands.
26.1 Command Summary
The following section lists the commands for this feature.
Table 66 ip Command Summary
COMMAND DESCRIPTION M P
show ip Displays current IP interfaces. E 0
ip name-server <ip> Sets the IP address of the domain name
server.
C13
ip address <ip> <mask> Sets the IP address of the MGMT port (for
out-of-band management) on the Switch.
E0
ip address default-gateway <ip> Sets the default gateway for the out-of-
band management interface on the Switch.
C13
show ip iptable all [IP|VID|PORT] Displays the IP address table. You can sort
the table based on the IP address, VLAN
ID or the port number.
E3
show ip iptable count Displays the number of IP interfaces
configured on the Switch.
E3
show ip iptable static Displays the static IP address table. E 3
Table 67 tcp and udp Command Summary
COMMAND DESCRIPTION M P
show ip tcp Displays IP TCP information. E 3
